Junction Box Electrical Potting Liquid Silicone Gel Insulation Waterproof Igbt

Brand Name:	Hanast
Model Number:	HN-6607AB
MOQ:	1kg
Price:	Negotiable
Packaging Details:	25KG/ Iron Drum
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong,China

Certification:

ROHS SGS

Feature:

Waterproof,soft,low-viscosity

Application:

Load Cell,power Module,PCB,circuit Board

Advantage:

Good Shock Absorption, Moisture Resistance

Sample:

1 Kilogram At Least

Keyword:

Waterproof Protective Electronic Potting Adhesive

Viscosity After Mixing（cp S. 25℃):

800～1500

Hardness:

Relative Density（mpa•s）:

A:1 ．0～1.12,B:0.98～1.02

Penetration (1/10mm):

200 ~400

Color:

Clear

Highlight:

Junction Box liquid silicone gel

Igbt liquid silicone gel

Igbt Electrical Potting Gel

Product Description

Junction Box Circuit Board Softness Electrical Insulation Silicone Gel Waterproof 2 Part For PCB Load Cell Gel Silicone Igbt

Product description:

HN-6607AB is a very soft, low crosslinking density addition silicone rubber

Product Features:

1. Medium temperature curing, the curing time can be adjusted according to different temperatures;

2. It is low-viscosity silicone oil before curing and gel elastomer after curing.

Characteristics before curing
Component	Component A	Component B
Color	Transparent liquid	Transparent liquid
viscosity(cp s. 25℃)	800～2000	800～1800
Relative density(mpa•s)	1 ．0～1.12	0.98～1.02
The mixing ratio	A:B=1:1
Viscosity after mixing(cp s. 25℃)	800～1500
Operate Time (25℃)	2 h
Penetration (1/10mm)	200~ 400
Curing conditions (120℃)	20~30 mins
Cured properties Hardness(Shore A, 24hr)	0～10

Junction Box Electrical Potting Liquid Silicone Gel Insulation Waterproof Igbt 0

Instructions:

1. Before mixing, component A needs to be properly stirred manually or mechanically, and component B should be fully shaken in a sealed state before use.

2. When it needs to be attached to the application material, please confirm whether it can be attached before use, and then apply it. 3. Before construction, please weigh and mix according to the weight ratio of A:B = 1:1, and stir thoroughly before applying glue.

Package:

This product is 40KG per group;

Component A is 20KG (in barrels), and Component B is 20KG (in barrels)
