Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM

Brand Name:	Hanast
Model Number:	HN-5508AB
MOQ:	1KG
Price:	6.25
Packaging Details:	Plastic/Iron Drums
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

Epoxy Resin Potting Glue

Color:

Black/Grey/Transparent Color, Can Customized

Application:

PCB/Battery/LED

Package:

5kgs/25kgs/200kgs/bag

Material:

Epoxy Resin&Agent

Keywords:

Waterproof Sealant

Viscosity:

Excellent Viscosity

Certificate:

MSDS RoHS UL

Feature:

Low And High Temperature Resistance

Thermal Conductivity:

Customize

Supply Ability:

1000000KG

Highlight:

Epoxy Potting Compound Raw Silicone

raw Epoxy Potting Compound

raw silicone rubber Epoxy

Product Description

2:1 Epoxy Potting Compound With Low Viscosity Long Operational Time Suitable for Transformers Resistors Filters Electronics

HN-5508 Epoxy Resin Potting Compound

Product Specification

Before curing	builder	Epoxy resin 5508	Curing agent 5508
	pigment	Black / White et al	Ruburn / transparent surface
	Surface	A sticky epoxy resin water	r liquid specific
	specific gravity, g / cm3	1.4-1.5	1.05
	Viscosity of 25℃	4,500—6,000cp s	150—250cp storage
	storage Period (25℃)	Six months	x months
processabilility	mixing ratio	A: B =5:1 (weight ratio)
	Available for a time of 25℃	2-3H (100g mix)
	curing time	25℃ / 6-8H surface stem, 12-16H fully cured or 60-80℃/1.5-2H
After curing	Tensile strength of kg/cm	16-18
	Compressive strength of kg/cm	18-22
	Resistance to the voltage of kv/mm	20-22
	Surface resistance ofΩ-cm	14
		1.2*10
	Volume resistance ofΩ-cm	15
		1.1*10
	contraction percentage%	0.35-0.55
	Water absorption rate was 25℃ * 24H	<0.03%
The hardness of SHORE A	85-95
Distortion temperature ℃	130-150
low temperature resistant ℃	-30

Product Describtion
HN-5508 is an epoxy potting compound suitable for industrial equipment. It has excellent temperature resistance, chemical resistance and mechanical strength. It is widely used in industrial applications such as high-voltage packaging, aquarium equipment and ultrasonic atomizers.

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 0

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 1

Product Highlights
High temperature resistance: The operating temperature range is -30°C to 130-150°C, suitable for extreme industrial environments.

Chemical resistance: Acid and alkali resistance, moisture resistance, aging resistance, suitable for harsh conditions.

High mechanical strength: Hardness 85-95 SHORE D, providing excellent compression and impact resistance.

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 2

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 3

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 4

Technical parameters
Viscosity (Component A: 4500-6000 cps, Component B: 150-250 cps)

Hardness (SHORE D): 85-95

Tensile strength: 16-18 kg/cm²

Compressive strength: 18-22 kg/cm²

Application scenarios
High-voltage packaging: used for insulation and protection of high-voltage equipment.

Aquarium equipment: Provide waterproof and moisture-proof sealing.

Ultrasonic atomizer: Enhance the durability and reliability of equipment.

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 5

Usage method
Mix according to the weight ratio of A:B = 5:1 and use.

Fully cure in 12-16 hours at 25℃, or 1.5-2 hours at 60-80℃.

Industrial 2:1 Epoxy Potting Compound Raw Silicone Rubber ODM 6

Packing specifications
30 KG/group (Component A 25 KG/barrel, Component B 5 KG/can)
