Hardness 40 Platinum Cure Liquid Silicone Rubber for Artificial Stone Mold Wall Tile

Hardness 40 Platinum-Cure (Addition) Liquid Silicone Rubber for Artificial Stone Mold & Wall Tile

This platinum-cure (addition) liquid silicone rubber is a two-component translucent system mixed at a 1:1 ratio by weight, supplied at the Hardness 40 Shore A grade. It cures at room temperature or with heat acceleration, offering low viscosity, good fluidity and reliable bubble release for precise mould reproduction. The cured silicone is food-grade, non-toxic, odourless and non-corrosive (FDA / MSDS / RoHS), with excellent physiological inertness, waterproof and ageing resistance, high tensile strength and toughness, temperature resistance from −50 °C to 200 °C, and extremely low shrinkage (≤ 0.1%) for high-precision artificial stone moulds and wall tile applications.

Key Features of Liquid Silicone Rubber

• Hardness 40 Shore A grade with 1:1 mix ratio (A:B by weight); 30–40 min pot life
• Translucent, food-grade: FDA, MSDS, RoHS certified; non-toxic, odourless, non-corrosive
• Low viscosity (6000 ± 500 mPa·s) for easy mixing and bubble removal; good fluidity for pouring
• Room-temperature cure (3–4 h) or heat-accelerated cure (80–100 °C, ≤ 20 min)
• High tensile strength (6.0 MPa), tear strength 14 kN/m and elongation up to 450%
• Operating temperature range −50 °C to 200 °C; excellent ageing and ozone resistance
• Extremely low shrinkage (≤ 0.1%) with no low-molecule release during cure; high precision

Typical Applications of Liquid Silicone Rubber

• Artificial stone mould making and wall tile production
• Resin, cement component, cultural stone and gypsum craft moulds
• High-grade / special-use mould making — concrete, high-wear rigid moulds
• General RTV mould applications requiring food-grade safety and high precision

Technical Data of Liquid Silicone Rubber

Mixing & Application Instructions

1. Pre-mix: Stir Components A and B thoroughly before use to ensure homogeneity.
2. Weighing: Accurately weigh A and B in a 1:1 ratio by weight using a precision scale.
3. Mixing: Mix A and B thoroughly for 2–3 minutes until uniform; scrape container walls and bottom.
4. Degassing: For bubble-free moulds, degas under vacuum to remove entrapped air.
5. Pouring: Pour into the clean, dry mould frame within the 30–40 min pot life; ensure full coverage.
6. Curing: Cure at room temperature for 3–4 h, or heat at 80–100 °C for ≤ 20 min. Demould after full cure.

Packaging

• Component A: 10 kg / 20 kg / 25 kg iron or plastic drum
• Component B: 10 kg / 20 kg / 25 kg iron or plastic drum
• Kit (A+B): 20 kg / 40 kg / 50 kg per set

Storage & Shelf Life

• Store in original, tightly sealed containers in a cool, dry, well-ventilated area below 25 °C.
• Protect from direct sunlight, moisture, heat and extreme temperatures.
• Shelf life: 12 months from date of manufacture when stored unopened and properly sealed.
