3:1 Epoxy Potting Compound Electrical Industrial Silicone Gel For Resistors

Brand Name:	Hanast
Model Number:	HN-5508AB
MOQ:	1KG
Price:	6.2
Packaging Details:	Plastic/Iron Drums
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Product Name:

Epoxy Resin Potting Glue

Color:

Black/Grey/Transparent Color, Can Customized

Application:

PCB/Battery/LED

Package:

5kgs/25kgs/200kgs/bag

Material:

Epoxy Resin&Agent

Keywords:

Waterproof Sealant

Viscosity:

Excellent Viscosity

Certificate:

MSDS RoHS UL

Feature:

Low And High Temperature Resistance

Thermal Conductivity:

Customize

Supply Ability:

1000000KG

Highlight:

Industrial Epoxy Potting Compound

resistors Epoxy Potting Compound

Potting industrial silicone gel

Product Description

3:1 Epoxy Potting Compound With Low Viscosity Long Operational Time Suitable for Transformers Sensors Resistors Filters PCB Battery Power Moulds Car Electronics Protection

HN-5508 Epoxy Resin Potting Glue

Product Specification

Before curing	builder	Epoxy resin 5508	Curing agent 5508
	pigment	Black / White et al	Ruburn / transparent surface
	Surface	A sticky epoxy resin water	r liquid specific
	specific gravity, g / cm3	1.4-1.5	1.05
	Viscosity of 25℃	4,500—6,000cp s	150—250cp storage
	storage Period (25℃)	Six months	x months
processabilility	mixing ratio	A: B =5:1 (weight ratio)
	Available for a time of 25℃	2-3H (100g mix)
	curing time	25℃ / 6-8H surface stem, 12-16H fully cured or 60-80℃/1.5-2H
After curing	Tensile strength of kg/cm	16-18
	Compressive strength of kg/cm	18-22
	Resistance to the voltage of kv/mm	20-22
	Surface resistance ofΩ-cm	14
		1.2*10
	Volume resistance ofΩ-cm	15
		1.1*10
	contraction percentage%	0.35-0.55
	Water absorption rate was 25℃ * 24H	<0.03%
The hardness of SHORE A	85-95
Distortion temperature ℃	130-150
low temperature resistant ℃	-30

Product Overview
HN-5508 is an epoxy potting compound designed for the electronics and electrical industry. It has low viscosity, high insulation and temperature resistance, and is suitable for potting and protection of electronic components such as transformers, resistors, filters, etc...

3:1 Epoxy Potting Compound Electrical Industrial Silicone Gel For Resistors 0

3:1 Epoxy Potting Compound Electrical Industrial Silicone Gel For Resistors 1

Key Features

✔ Low Viscosity – Ensures deep penetration into intricate components.
✔ High Performance – Shore D hardness of 85–95, tensile strength of 16–18 kg/cm², and compressive strength of 18–22 kg/cm².
✔ Exceptional Electrical Properties – Volume resistivity: 1.1×10¹⁵ Ω·cm; dielectric strength: 20–22 kV/mm.
✔ Wide Temperature Range – Operates from -30°C to 130–150°C, suitable for harsh environments.
✔ Flame Retardant & Moisture-Resistant – Protects against humidity, dust, and chemical exposure.
✔ Environmentally Compliant – Meets EU RoHS Directive standards.

3:1 Epoxy Potting Compound Electrical Industrial Silicone Gel For Resistors 2

Application areas
Electronic appliances: transformers, resistors, filters, temperature sensors, etc.

Industrial equipment: high voltage packaging, aquarium equipment, ultrasonic atomizers, etc.

Others: components that require insulation, flame retardancy and temperature resistance.

Application scenarios
Transformer potting: Provides excellent insulation and moisture protection.

Sensor encapsulation: Enhances sensor durability and reliability.

Filter protection: Prevents dust and moisture intrusion and extends service life.

3:1 Epoxy Potting Compound Electrical Industrial Silicone Gel For Resistors 4

Technical parameters
Viscosity (Component A: 4500-6000 cps, Component B: 150-250 cps)

Hardness (SHORE D): 85-95

Tensile strength: 16-18 kg/cm²

Compressive strength: 18-22 kg/cm²

Packaging and ordering
30 KG/group (A component 25 KG/barrel, B component 5 KG/can)

Supports customized services to meet different customer needs.

3:1 Epoxy Potting Compound Electrical Industrial Silicone Gel For Resistors 5
