High Thermal Conductivity Silicone Potting Compound One To One Ratio For New Energy Power Module Heat Dissipation
Product Overview for silicone potting compound:
Delivering dependable performance for automotive electronics, HN-8806 complies with rigorous automotive-grade standards. It boasts outstanding thermal conductivity, flame retardancy, electrical insulation and anti-vibration properties, making it the preferred potting material for EV battery packs, BMS boards, motor control units and on-board chargers.
Key Features for silicone potting compound:
Automotive-Grade Reliability
Balanced Superior Performance: Thermal Conduction, Flame Retardancy & Electrical Insulation
Long-Lasting Environmental Barrier Protection
Non-Corrosive Formula
Outstanding Vibration and Shock Resistance
Technical Parameters for silicone potting compound:
| Thermal Conductivity |
≥0.76 W/m·K |
| Flame Retardancy Rating |
UL 94V-0 |
| Volume Resistivity |
1.0×10¹⁶ Ω·cm |
| Operating Temperature Range |
-50°C ~ +250°C |
| Hardness (Shore A) |
45±5 |
| Mix ratio |
1:1 |
Product Applications for silicone potting compound:
Master & slave boards of Battery Management System (BMS), Motor Control Units (MCU), On-Board Chargers (OBC)
Position sensors, pressure sensors, radar circuit assemblies
Vehicle Domain Controllers
Circuit protection encapsulation for body control and vehicle control modules
Usage Instructions for silicone potting compound:
Operate in accordance with standard operating procedures; maintain a clean working environment and ensure complete uniform mixing.
Strengthen process control and retain complete batch records when processing automotive-grade assemblies.
Packaging & Storage for silicone potting compound:
Standard Packaging
Component A: 25 kg per drum; Component B: 25 kg per drum.
Storage & Shelf Life
Keep stored in cool and dry conditions. The shelf life is 6 months for unopened original packaging.
FAQ for silicone potting compound:
Q: Does it have any specific automotive certifications?
A: The formulation meets the high-reliability requirements for automotive electronics. Its performance targets meet or exceed general automotive standards.
Q: Is it corrosive to BMS circuit boards?
A: Not at all. It cures without by-products and is non-corrosive to metals like copper and aluminum.
Q: How does it ensure vibration reliability?
A: The elastomer absorbs and dissipates vibration and shock energy, protecting solder joints and fragile components.
Q: Can I get a sample for testing?
A: Absolutely! We are happy to provide free samples to potential customers for evaluation.
Q: Do you support custom formulations?
A: Yes, we have strong R&D capabilities and can collaborate to develop customized potting solutions.
