Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances

Brand Name:	Hanast
Model Number:	HN-8808
MOQ:	1 kilogram
Price:	Negotiable
Packaging Details:	25KG/ Iron Drum
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ROHS，SGS

Material:

Silicone

Appearance:

Liquid

Application:

Electronic Appliances

Mix Ratio:

Type:

2 Parts

Feature:

Good Adhesion, No Corrosion

Color:

Transparent,white,black

Wide Temperature Range:

-50℃-200℃

Waterproof:

Usage:

Circuit Boards, LED Power Supplies, Waterproof Power Supplies

Highlight:

Moisture Proof Silicone Potting Compound

Silicone Potting Compound Material

Compound silicone rubber raw material

Product Description

10:1 Potting Compound Insulation Moisture-proof AB Glue Potting Adhesive Black Two-component Silicone Adjustable Customization For Electronic Appliances

Product Description

Potting glue HN- 8808AB, is a two-component condensation type room temperature curing silicone rubber, also known as RTV 2 Liquid Silicone Rubber, composed of two parts of A and B. After the A and B components are mixed at 10:1 (mixed ratio), they solidify into a high-performance elastomer through a condensation reaction.

Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances 0

Product Features

1) Good adhesion, no corrosion

2) solid Small chemical shrinkage,

3) no heat release, good insulation,

4) wide temperature range (-50℃-200℃),

5) waterproof and moisture-proof

Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances 1

Main Application

Electronic components, solar energy, backlight, electrical module

Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances 2

Technical Sheet

Before Mixing
	A	B
Exterior	black liquid	Transparent liquid
Base chemical composition	Polysiloxane	Polysiloxane
Viscosity (cP) (GB/2794-1995)	2000-2800	20-30
Density (g/cm³) (GB/2794-1995)	1.42±0.02	-
A+B after mixing
Exterior	black liquid
Base chemical composition	Polysiloxane (Silicone)
Viscosity (cP) (GB/2794-1995)	2000-2600mpa's
Density (g/cm³) (GB/2794-1995)	1.40±0.02
Operating time (25℃, min)	40-60
Curing time (25℃, h)	4-6
Hardness (shore A) (GB/T531-1999)	30-40

Volume resistivity Ω·cm (GB/T 31838.2-2019)	≥5.0×10 14
Thermal conductivity (W/M▪K) (GB/T 38712-2020)	0.5±0.1
Dielectric strength (kv/mm)	≥14
Dielectric constant	≤3.5
Elongation at break (%)	≤100%

Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances 3

Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances 4

Packaging Method

22kg/set (component A 20kg + component B 2kg)

11kg/set (component A 10kg + component B 1kg)

Moisture Proof AB Silicone Potting Compound Rubber Raw Material For Electronic Appliances 5

Attention

1. The rubber material should be sealed and stored. Use the mixed glue at one time to avoid waste.

2. 10:1 colloid cannot be heated to accelerate solidification after mixing.

3. This product is a non-dangerous product, but please keep it out of your mouth and eyes.

4. This product is non-toxic and non-dangerous. Avoid rain and exposure. Store in a cool and dry place. The shelf life is6months (best use period3 within months)
