Industrial Electronic Thermally Conductive Silicone Potting Compound Gel High Temp

Name: Industrial Electronic Thermally Conductive Silicone Potting Compound Gel High Temp
Brand: Shenzhen Hanast New Material co.,LTD
SKU: HN-8806AB
Availability: InStock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Hanast
Certification:	ROHS SGS
Model Number:	HN-8806AB

Detail Information

Place of Origin:

Guangdong, China

Brand Name:

Hanast

Certification:

ROHS SGS

Model Number:

HN-8806AB

Name:

Potting Glue 1:1

Feature:

Moisture-proof, Dust-proof, Corrosion-proof, Shock-proof

Application:

Power Supply Automotive Electronics

Sample:

1kg

Regular Color:

Grey,black,white

Advantages:

Excellent Thermal Conductivity

Highlight:

High Light

Highlight:

industrial thermally conductive silicone potting compound

Electronic thermally conductive silicone potting compound

High Temp industrial silicone gel

Trading Information

Minimum Order Quantity:

1kg

Price:

Negotiable

Packaging Details:

25KG/barrel

Payment Terms:

T/T

Product Description

High Temp Potting Compound 1:1 Electronic Potting Silicone Rubber For Automotive Electronics Moisture-Proof Electrical Insulation Inverter Sensor Power Module Battery Silicone Glue

Product Description:

Two-component addition type silicone potting rubber for electronic components, which can be cured into high-performance elastomer by room temperature or heating.

Industrial Electronic Thermally Conductive Silicone Potting Compound Gel High Temp

Technical Parameters

Test Items	Test Standard	Units	Product test results
Test Items	Test Standard	Units	Part A	Part B
Before curing	1	Appearance	---	---	Grey, fluid	White, fluid
	2	Viscosity	GB/T10247-2008	25ºC, mPa·S	4500~5000	4500~5000
	3	Density	GB/T 13354-92	25ºC, g/cm³	1.50±0.05	1.50±0.05
	4	Mixing Ratio (A : B)	1:01	Weight ratio	100	100
		Mixing Ratio (A : B)	1:01	Volume ratio	100	100
	5	Operating time	Measured	hr	0.3-0.4
	6	Curing condition	Measured	hr	4^12 (25ºC,initial cure)
	6	Curing condition	Measured	hr	0.20 (80ºC)
After Curing	7	Appearance	---	---	Grey elastomer
	8	Hardness	GB/T 531.1-2008	Shore A	50±5
	9	Thermal conductivity	GB/T10297-1998	w/m·k	≥0.76
	10	Expansivity	GB/T20673-2006	μm/(m,ºC)	210
	11	Moisture Absorption	GB/T 8810-2005	24h,25ºC, %	0.01~0.02
	12	Volume resistivity	GB/T 1692-92	(DC500V),Ω · cm	1.0×10¹⁵
	13	Dielectric intensity	GB/T 1693-2007	Kv/mm(25ºC)	18^25
	14	Temperature Resistance	Measured	ºC	-50~+250°c

HN-8806 A/B (1:1)
* Features :
Flexible Rubber – Protects components against thermal cycling stress and mechanical shock.
Low shrinkage rate, no corrosion of components after curing.
Flame retardant, high and low temperature resistance from -50ºC to 250ºC (58°F to 432°F).
Excellent electrical properties and Thermal conductivity.
* Color : Grey (can be customized)

Industrial Electronic Thermally Conductive Silicone Potting Compound Gel High Temp

Industrial Electronic Thermally Conductive Silicone Potting Compound Gel High Temp
* Packing :
10KG / Set (A, 5kg + B, 5kg)
20KG / Set (A, 10kg + B, 10kg)
50KG / Set (A, 25kg + B, 25kg)

Industrial Electronic Thermally Conductive Silicone Potting Compound Gel High Temp
