High Hardness Chemical Resistant Epoxy Potting Glue Automotive Marine and Industrial Applications for Transformers Resistors Filters Electronics
HN-5508 Epoxy Resin Potting Compound
Product Specification
| Before curing |
builder |
Epoxy resin 5508 |
Curing agent 5508 |
| pigment |
Black / White et al |
Ruburn / transparent surface |
| Surface |
A sticky epoxy resin water |
r liquid specific |
| specific gravity, g / cm3 |
1.4-1.5 |
1.05 |
| Viscosity of 25℃ |
4,500—6,000cp s |
150—250cp storage |
| storage Period (25℃) |
Six months |
x months |
| processabilility |
mixing ratio |
A: B =5:1 (weight ratio) |
| Available for a time of 25℃ |
2-3H (100g mix) |
| curing time |
25℃ / 6-8H surface stem, 12-16H fully cured or 60-80℃/1.5-2H |
| After curing |
Tensile strength of kg/cm |
16-18 |
| Compressive strength of kg/cm |
18-22 |
| Resistance to the voltage of kv/mm |
20-22 |
| Surface resistance ofΩ-cm |
14 |
| 1.2*10 |
| Volume resistance ofΩ-cm |
15 |
| 1.1*10 |
| contraction percentage% |
0.35-0.55 |
| Water absorption rate was 25℃ * 24H |
<0.03% |
| The hardness of SHORE A |
85-95 |
| Distortion temperature ℃ |
130-150 |
| low temperature resistant ℃ |
-30 |
Product Describtion
HN-5508 is an epoxy potting compound suitable for industrial equipment. It has excellent temperature resistance, chemical resistance and mechanical strength. It is widely used in industrial applications such as high-voltage packaging, aquarium equipment and ultrasonic atomizers.
Product Highlights
High temperature resistance: The operating temperature range is -30°C to 130-150°C, suitable for extreme industrial environments.
Chemical resistance: Acid and alkali resistance, moisture resistance, aging resistance, suitable for harsh conditions.
High mechanical strength: Hardness 85-95 SHORE D, providing excellent compression and impact resistance.
Technical parameters
Viscosity (Component A: 4500-6000 cps, Component B: 150-250 cps)
Hardness (SHORE D): 85-95
Tensile strength: 16-18 kg/cm²
Compressive strength: 18-22 kg/cm²
Application scenarios
High-voltage packaging: used for insulation and protection of high-voltage equipment.
Aquarium equipment: Provide waterproof and moisture-proof sealing.
Ultrasonic atomizer: Enhance the durability and reliability of equipment.
Usage method
Mix according to the weight ratio of A:B = 5:1 and use.
Fully cure in 12-16 hours at 25℃, or 1.5-2 hours at 60-80℃.
Packing specifications
30 KG/group (Component A 25 KG/barrel, Component B 5 KG/can)
