Customized Industrial Electronic Silicone Potting Compound Adhesive Corrosion Resistance

Brand Name:	Hanast
Model Number:	HN-8806AB
MOQ:	1kg
Price:	Negotiable
Packaging Details:	25KG/barrel
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

GuangDong,China

Certification:

ROHS SGS

Feature:

Insulation, Waterproof, Corrosion Resistance

Application:

Electronic Components, Solar Energy

Appearance:

Grey Fluid,black Fluid,white Fluid

Operating Time:

30-40mins

Color:

Can Be Customized

Sample:

Free Sample

Highlight:

Corrosion Resistance Silicone Potting Compound

industrial Silicone Potting Compound

Customized industrial silicone gel

Product Description

Factory Color Customized Flexible Electronic Potting Adhesive Two-Component Potting Compound Insulation Waterproof Corrosion Resistance Silicone Glue

PRODUCT DESCRIPTION

HN-8806, two-components addition type silicone potting rubber which can be cured into high-performance elastomer by room temperature or heating.

Customized Industrial Electronic Silicone Potting Compound Adhesive Corrosion Resistance 0

PRODUCT FEATURE

Excellent electrical insulation;

High moisture resistance: -50°C to 250°C;

Low viscosity ; Low shrinkage rate after curing;

No pollution in the surrounding environment.

Good thermal conductivity

Test Items	Test Standard	Units	Product test results
Test Items	Test Standard	Units	Part A	Part B
Before Curing	1	Appearance	By eyes	---	Grey, fluid	White, fluid
	2	Viscosity	GB/T10247- 2008	25ºC,mPa·S	4500~5000	4500~5000
	3	Density	GB/T 13354-92	25ºC,g/cm3	1.50±0.05	1.50±0.05
	4	Mixing Ratio (A : B)	1:1	Weight ratio	100	100
	4	Mixing Ratio (A : B)	1:1	Volume ratio	100	100
	5	Operating time	Measured	hr	0.3-0.4
	6	Curing condition	Measured	hr	4~12 (25ºC, initial cure)
	6	Curing condition	Measured	hr	0.20 (80ºC)
After Curing	7	Appearance	By eyes	---	Grey Elastomer
	8	Hardness	GB/T 531.1-2008	Shore A	50±5
	9	Thermal conductivity	GB/T10297-1998	w/m·k	≥0.76
	10	Expansivity	GB/T20673-2006	µm/(m,ºC)	210
	11	Moisture Absorption	GB/T 8810-2005	24h,25ºC,%	0.01~0.02
	12	Volume resistivity	GB/T 1692-92	(DC500V),Ω· cm	1.0×1016
	13	Dielectric intensity	GB/T 1693-2007	Kv/mm(25ºC)	18~25
	14	Temperature Resistance	Measured	ºC	-50~+250

HOW TO USE

1. When used, weigh A and B according to proportion and then mix them evenly.

Mix thoroughly and evenly with a clean stirring device in a clean container, and then potting can be done.

It can also be sealed under a vacuum after removing the bubbles.

2. The surface of the potting element needs to be cleaned.

If the potting product is too large, it is recommended to potting in stages and then cure at room temperature (4-12hr) or by heating (80ºC-0.5hr).

3. For the automatic potting production line, in order to ensure accurate mixing ratio of A and B, Part A and Part B should be vacuumed respectively to remove the bubbles (the foaming time is 5-10 minutes), and then A and B should be pumped to the static mixer in proportion with a metering pump, and then potting can be done after mixing evenly.
